MC200 ATP Hygiene Monitor
Model: MC200 | Brand: FSTest
10 seconds Instant RLU Reading | 10⁻¹⁶ mol Detection Sensitivity | 300g Portable Handheld Field Use | Cloud Sync Data Management |
The FSTest MC200 ATP Hygiene Monitor is a next-generation handheld luminometer designed for real-time quantitative verification of surface cleanliness and CIP water hygiene.
Based on firefly luciferin-luciferase bioluminescence chemistry, the MC200 quantifies Adenosine Triphosphate (ATP) from both organic residues and microbial contamination. It displays precise Relative Light Unit (RLU) results in just 10 seconds. Featuring an intuitive touchscreen interface, USB/Bluetooth connectivity, and robust audit trail software, the MC200 helps food safety managers maintain strict HACCP and GMP sanitation compliance.
Rapid 10-Second Results: Instantly verify sanitation effectiveness on production lines before starting a new batch.
Ultra-High Detection Limit: High-sensitivity photomultiplier tube detects ATP down to 1×10⁻¹⁶ moles.
Smart Pass/Caution/Fail Limits: Customizable location-based thresholds give operators clear visual feedback for immediate re-cleaning decisions.
Seamless Data Management: Built-in memory stores thousands of test records; export data via USB or Bluetooth to generating automated audit reports.
Ergonomic & Portable Design: Lightweight (approx. 300g) with a rechargeable lithium battery supporting over 8 hours of continuous field testing.
| Product Name | MC200 ATP Hygiene Monitor |
|---|---|
| Model | MC200 |
| Detection Technology | Firefly Bioluminescence / PMT Optical Sensor |
| Detection Limit & Range | 1 × 10⁻¹⁶ mol ATP; 0 – 999,999 RLUs |
| Test Time | 10 seconds |
| Data Storage & Connectivity | Stores up to 20,000 test results; USB & Bluetooth |
| Power Supply & Weight | Rechargeable Lithium Battery; Approx. 300g |
Ideal for hygiene inspection and cross-contamination monitoring across multiple sectors:
STEP 1 Swab Swab a 10 × 10 cm test area thoroughly using a pre-moistened ATP QuickTest swab. | STEP 2 Activate Snap the top valve, squeeze liquid extractant down, and shake 5–10 times to mix. | STEP 3 Insert Insert activated swab into the MC200 reading chamber and close lid. | STEP 4 Read Get RLU score and Pass/Fail result on screen in 10s; auto-save data for reporting. |
The FSTest MC200 ATP Hygiene Monitor delivers professional-grade accuracy and repeatability:
High Optical Linearity: Linear RLU output across a wide 0–999,999 RLU dynamic range (R² > 0.99).
Low Background Interference: Sealed optical chamber blocks ambient light leaks for minimal background noise.
CE & ISO Compliance: Built to ISO 9001 standards and compliant with CE electrical safety requirements.
FSTest ATP Swab - QuickTest (CatNO: 22101): Surface sampling swab pre-moistened with ATP extractant and firefly enzyme.
Water ATP Testing Kit: Specialized liquid sampling swabs for total and dissolved ATP testing in CIP rinse water.
Calibration Rod Kit: Positive and negative LED calibration rods for routine optical instrument verification.
